2MB RS232 BTM WORKABOUT MX

Processor       :   16 bit NEC V30MX running at 27.684 MHz (80C86 compatible)

MEMORY        :   2MB Byte RAM CAPACITY: Two (2) Solid OPERATING:    EPOC/16 operating system featuring pre-emptive multi-tasking,

SYSTEM                graphics support, graphical user interface and DOS-like line processor.

POWER           :    Internal: 2 x AA alkaline cells or NiMh pack

SUPPLY                 External: power and battery charging provided by Psion Docking

Holster, Docking Station and Multiple Docking Stations.

EXPANSION    :    Factory fitted internal expansion options available interface

INTERFACES        options include:

RS232 (115,200 baud) the tethered barcode and wand connection

RS232 Communication port to PC






EXTECH 3500THS SERIES

PRINT BUFFER       :    32K Standard

PRINT METHOD     :    Direct Thermal

PAPER WIDTH       :    80 mm (3.12 inches) or 57mm (2.24 inches)

BATTERY PACK      :    7 cell NiMH 700mAH Rechargeable

DIMENSIONS         :    6” W x 4.75” L x 2.75” H

WEIGHT                  :    580g (20.0 oz) with paper and battery pack

SPECIAL                  :    Downloadable fonts, barcodes, forms and logos

FEATURES

INFRA-RED (IRDA):    Standard
